Mimaki TXF300-75
Designed for high-productivity DTF transfer printing,the TXF300-75 offers 300% faster speeds than the entry-level TxF150-75, combined with automated nozzle checking and white ink circulation for minimal downtime.
Key Features & Capabilities
-
Dual Print Head Architecture: Equipped with two staggered, on-demand piezo print heads, achieving print speeds up to 107.6 sq ft/hr (10 m²/hr).
-
Mimaki Circulation Technology (MCT): Continuously circulates white ink through the supply lines and damper to prevent settling and nozzle clogging.
-
Degassed Aluminum Ink Packs: Uses eco-friendly PHT50 heat transfer pigment inks packaged in aluminum bags to prevent air bubbles and oxidation from disrupting ink flow.
-
Automated Reliability (NCU & NRS): Features a Nozzle Check Unit to detect blocked nozzles and a Nozzle Recovery System to automatically map around unusable nozzles until cleaning occurs.
-
OEKO-TEX® ECO PASSPORT Certified: Safe for printing skin-friendly textiles, including cotton, polyester, blunted blends, and dark fabrics.
-
3-Way Intelligent Heater: Accelerates drying on film to prevent blurring and maintain precise dot placement.
Technical Specifications Summary
| Feature | Specification |
| Max Print Width | 31.5 inches (800 mm) |
| Max Media Width | 31.9 inches (810 mm) |
| Print Resolution | 720 dpi / 1,080 dpi / 1,440 dpi |
| Ink System | PHT50 Heat Transfer Pigment (C, M, Y, K, White) |
| Ink Capacity | 600 ml degassed packs (500 ml for White) |
| Connectivity | Gigabit Ethernet (1000 BASE-T) & USB 2.0 |
| Supported Software | Mimaki RasterLink7 RI |
